Stainless hlau actuators yog siv tau, lub sij hawm ntev txaus automation kev daws teeb meem los tswj cov dej ntws ntawm cov hlau ua haujlwm, compressed cua, thiab cov khoom pov tseg. Cov kua dej no dais cov khoom siv tshuaj thiab lub cev sib txawv uas cuam tshuam rau lub valve thiab actuator kev ua tau zoo thiab kav ntev.
Cov kua dej ua haujlwm hlau, xws li txiav cov roj thiab cov khoom ua kom txias, tuaj yeem muaj cov tshuaj uas yuav ua rau corrosive lossis abrasive. Stainless hlau actuators tuaj yeem tiv taus cov cheeb tsam hnyav no, ua kom muaj kev sib luag thiab meej ntawm cov dej ntws.
Compressed cua yog lwm qhov nruab nrab hauv cov txheej txheem kev lag luam, thiab stainless hlau actuators tuaj yeem tswj tau nws cov dej ntws zoo. Lub durability ntawm stainless hlau pab tiv thaiv kev hnav thiab tsim kua muag, kom ntseeg tau tias kev ua haujlwm ntev thiab txo cov kev tu ncua.
Kev lag luam pov tseg tuaj yeem ua rau corrosive heev thiab muaj cov khoom hnyav. Stainless hlau actuators muab kev tiv thaiv zoo heev rau tshuaj tua kab mob, ua rau lawv tsim nyog rau kev tswj cov dej ntws.
Zuag qhia tag nrho, stainless hlau actuators muab kev sib xyaw ua ke ntawm lub zog, ua haujlwm ntev, thiab tshuaj lom neeg ua haujlwm, ua rau lawv muaj kev ntseeg siab rau cov kev daws teeb meem automation hauv kev lag luam.
Technical Parameter
XM STAINLESS HLAU STEEL PNEUMATIC ACTUATOR OUTPUT TORQUE TABLE
|
Qauv |
Input cua siab (unit: bar) |
|||||
|
3 |
4 |
5 |
6 |
7 |
8 |
|
|
Cua siab tso zis torque (Nm) |
||||||
|
XM-DA45-SS |
7.2 |
9.6 |
12.0 |
14.4 |
16.8 |
19.2 |
|
XM-DA52-SS |
12.0 |
16.0 |
20.0 |
24.0 |
28.0 |
32.0 |
|
XM-DA63-SS |
21.7 |
28.9 |
36.0 |
43.4 |
50.6 |
57.8 |
|
XM-DA75-SS |
30.0 |
40.0 |
50.0 |
60.0 |
70.0 |
80.0 |
|
XM-DA83-SS |
46.8 |
62.4 |
78.0 |
93.6 |
109.2 |
124.8 |
|
XM-DA92-SS |
67.6 |
90.1 |
112.6 |
135.2 |
157.7 |
180.2 |
|
XM-DA105-SS |
97.7 |
130.3 |
162.9 |
195.5 |
228.0 |
260.6 |
|
XM-DA125-SS |
150.5 |
200.6 |
250.8 |
301.0 |
351.1 |
401.3 |
|
XM-DA140-SS |
260.7 |
347.6 |
433.8 |
521.4 |
608.3 |
695.2 |
|
XM-DA160-SS |
397.2 |
529.6 |
662.0 |
794.4 |
926.8 |
1059.2 |
|
XM-DA190-SS |
640.2 |
853.6 |
1067.0 |
1280.4 |
1493.8 |
1707.2 |
|
XM-DA210-SS |
798.0 |
1064.0 |
1330.0 |
1596.0 |
1862.0 |
2128.0 |
|
XM-DA240-SS |
1154.3 |
1539.0 |
1923.8 |
2308.5 |
2693.3 |
3078.0 |
|
XM-DA270-SS |
1755.0 |
2340.0 |
2924.0 |
3510.0 |
4095.0 |
4680.0 |
|
XM-DA300-SS |
2291.4 |
3055.2 |
3819.0 |
4582.8 |
5346.6 |
6110.4 |
|
XM-DA350-SS |
3426.0 |
4568.0 |
5710.0 |
6852.0 |
7994.0 |
9136.0 |
|
XM-DA400-SS |
4872.0 |
6496.0 |
8120.0 |
9744.0 |
11368.0 |
12992.0 |
Nco ntsoov tsom mus rau qhov zoo dua Pneumatic Actuators, tiv tauj peb!
Tsis muaj teeb meem pneumatic actuator to, tiv tauj peb!
Pneumatic Actuators nrog cov ntaub ntawv muaj tseeb torquehauv catalogues, tiv tauj peb!(Peb muaj torque ntsuas tshuab los ntawm peb tus kheej.)
