Hauv siab -siab valve automation systems, kev xaiv actuator tsis tshua muaj tsuas yog txog kev ua tiav 90-degree tig. Qhov kev sib tw tiag tiag yog tsim kom muaj lub zog txaus ntawm cov ntsiab lus tseeb uas lub valve muaj kev tiv thaiv siab tshaj plaws - tshwj xeeb tshaj yog thaum lub sijhawm tawg thiab zaum kawg.
Qhov no yog vim li cas scotch yoke pneumatic actuators tau dav siv hauv hnyav -lub quarter- tig valve daim ntawv thov hla cov roj & roj, petrochemical, LNG, tsim hluav taws xob, thiab cov kav dej.
Piv nrog rau khib thiab pinion actuators, lub scotch yoke mechanism tsim ib qho kev sib txawv torque nkhaus uas zoo dua qhov kev ua haujlwm ntawm tus npauj npaim li qub, pob li qub, thiab ntsaws li qub. Hauv kev lag luam tiag tiag, cov li qub no feem ntau xav tau lub zog siab dua thaum pib thiab xaus ntawm cov hlab ntsha vim kev sib txhuam ntawm lub rooj zaum, qhov sib txawv siab, kev tsim tawm, lossis kev ua haujlwm ntev.
Rau qhov loj - txoj kab uas hla li qub, tsis txaus torque breakaway tuaj yeem ua rau qeeb stroking, ua haujlwm tsis ruaj khov, lossis qhib valve tsis tiav. Hauv kev kaw cov ntawv thov, qhov kawg tsis txaus- txoj hauj lwm torque yuav ua rau qhov ua tau zoo ntawm kev sib khi tsis zoo lossis sab hauv to tom qab rov ua dua. Scotch yoke pneumatic actuators yog tsim tshwj xeeb los daws cov teeb meem no.
Khoom Specifications
| Lub kaum sab xis tig | 0 - 90 degree |
| Khoom siv | Cov hlau / carbon hlau |
| Maximum tso zis torque |
Ob npaug - ua haujlwm: 250,000 Nm Caij nplooj ntoos hlav pib dua: 140,000 Nm |
| Ua hauj lwm siab | 0.3 - 0.6 MPa |
| Ua haujlwm kub | Txheem: -20 rau +80 degrees Celsius |
Kev siv ntau hauv Industrial Valve Automation
Scotch yoke pneumatic actuators feem ntau tau teeb tsa hauv cov tshuab uas kaw siab - tawm kev ntseeg tau thiab ruaj khov torque kev ua tau zoo yog qhov tseem ceeb.
Cov ntawv thov ib txwm muaj xws li:
- Pipeline rho tawm li qub
- Thaum muaj xwm ceev shutdown systems
- Siab -siab npauj npaim li qub
- Loj pob valve automation
- LNG hloov pauv systems
- Refinery txheej txheem kab
- Offshore ntau lawm platforms
- Tank ua liaj ua teb valve tswj systems
Hauv ntau qhov chaw no, tus actuator tsis ua haujlwm tsis yog ib qho teeb meem txij nkawm - nws tuaj yeem cuam tshuam ncaj qha rau cov txheej txheem kev nyab xeeb, kev ua raws li ib puag ncig, thiab kev tsim khoom txuas ntxiv.
Scotch yoke pneumatic actuators tseem yog ib qho ntawm cov kev daws teeb meem ntau tshaj plaws rau siab torque valve automation vim tias lawv tau tsim nyob ib puag ncig kev lag luam kev lag luam tiag tiag es tsis yog qhov txiaj ntsig tso tawm ib leeg. Lawv lub peev xwm los xa cov torque txhim khu kev qha qhov twg li qub xav tau nws ua rau lawv tshwj xeeb tshaj yog tsim nyog rau kev thov cov txheej txheem tswj thiab kev siv kaw thaum muaj xwm txheej ceev.
